Hydro Testing Corrosion Inhibitor RXSOL 4000 is Hydro-testing corrosion protection for Pipeline, Tank. RXSOL 4000 Chemical for conditioning of hydro test water i.e. blend of corrosion inhibitor, one Oxygen scavenger, one scale inhibitor & one biocide manufacturer exporter and supplier Mumbai, Surat, Gandhidham, Chennai, Ennore, Visakhapatnam, Kolkata, Haldia, Paradip, Fujairah, Sharjah, Ajman, Abudhabi, Dubai UAE Middle East, Muscat Oman Sohar
RXMARINE CHEMICAL TAG::
Hydro Testing Corrosion Inhibitor RXSOL 4000 is a multicomponent, multifunctional formulation which prevents corrosion, microbiological growth in single product treatment programme. Inhibitor, corrosion, multicomponent, multifunctional: For prevention of corrosion and microbiological growth in water flood systems during hydrostatic testing and other applications.
Hydro Testing Corrosion Inhibitor RXSOL 4000 is a cocktail of water soluble chemicals designed to protect pipelines from corrosion during hydrostatic testing and mothball operations. Hydro Testing Corrosion Inhibitor RXSOL 4000 incorporates oxygen scavenger to rapidly remove oxygen, biocide to prevent Microbial Influenced Corrosion (MIC), together with a film forming corrosion inhibitor to combat acid (low pH) corrosion. Hydro Testing Corrosion Inhibitor RXSOL 4000 represents a single stage treatment chemical treatment, for hydrotest and mothball operations. Hydro Testing Corrosion Inhibitor RXSOL 4000 is a completely soluble product in fresh water, seawater and in most oilfield brine solutions. It is, therefore, suitable for use in water injection systems (which have no mechanical deaeration), hydrotest and mothball operations, and as a packer fluid. Hydro Testing Corrosion Inhibitor RXSOL 4000 has been used in a large number of major projects in the North Sea, Latin America and South East Asia.
Risk of serious damage to eyes. In case of contact with eyes, rinse immediately with plenty of water & seek medical advice. Wear suitable gloves and eye / face protection
Chemical for conditioning of hydro test water i.e. blend of corrosion inhibitor, one Oxygen scavenger, one scale inhibitor & one biocide
Benefit / Advantage of Hydro Testing Corrosion Inhibitor RXSOL 4000
- Hydro Testing Corrosion Inhibitor RXSOL 4000 is a liquid multifunctional chemical designed to completely treat hydrostatic test fluid, saltwater packer fluid, saltwater drilling fluid, during Hydro-testing and oil field water injection programme.
- Hydro Testing Corrosion Inhibitor RXSOL 4000 contains an effective filming corrosion inhibitor, oxygen scavenger and biocide, altogether in a single formulation convenient to dose with single chemical injection pump or skid.
- Hydro Testing Corrosion Inhibitor RXSOL 4000 is economical to use as handling is limited to one chemical.
- Rapidly kills Sulphate Reducing (SRB) as well as other offending bacteria that give rise to Microbial Influenced Corrosion (MIC)
- Mitigates against acid corrosion resulting from residual low pH of surface waters
Form Liquid
ColourColourless to slightly Yellow
OdourSharp
Flash Point > 100 degree C
Density1.05-1.11 g/cm3 (25 degree C)
pH3 - 7
Non-Flammable
Safe Plant Handling
Low Odor
Provides corrosion protection in the liquid and the vapor phase
When used in hydrostatic testing the product provides protection in liquids below, above and at the liquid levels. Protection of recessed and hard to reach areas. Complicated valves and the interior surfaces of piping and equipment, which are often difficult or impossible to reach, are protected with true Vapor Corrosion Inhibitor action. Can be applied for hydrotest solution, metalworking fluids, coatings, adhesives and water treatment formulations.
PERFORMANCE:
CORROSION: Effectively prevents corrosion due to Carbon Dioxide, inorganic salts, dissolved oxygen & Hydrogen sulphide contamination from sour fluid or bacterial action. The inhibitor acts as a cathodic polarizer
MICROBIOLOGICAL GROWTH: Effectively prevents the metabolic function necessary for reproduction of the bacteria cell. Successfully prevents anaerobic/aerobic and sulphate reducing bacteria.
Effect of Micro – Organisms:
All water used for Hydro-testing generally contains iron bacteria and sulphate reducing bacteria. The iron bacteria attack to the pipe wall mostly at 6 o’clock location and produces tubercle of iron oxide by metabolic action. Below the tubercles, sulphate reducing bacteria grows and generates H2S from sulphate of water. The H2S goes on reacting with iron forming Fe2S. This is combined with auto catalytic formation of HCI under tubercle and lead to deep pitting and perforation of the pipe wall. The mechanism is more pronounced under stagnant condition and is relevant of Hydrostatic testing.
#HydroTestingINHIBITOR_UAE
Hydro Testing Corrosion Inhibitor ( RXSOL 4000 ) can be fed directly or through chemical doses pump. Doses may vary with the quality of water to be treated and the residence time of the water in the system.
Actual consumption is determined under operating conditions.
Recommended Dosage of Hydro Testing Corrosion Inhibitor RXSOL 4000
Hydro Testing Corrosion Inhibitor RXSOL 4000 dosage levels typically are 500ppm for hydrotest operations and between 1000- 4000 ppm when used as a packer fluid inhibitor. The exact dose rate for a specific job would depend on the environment and fluid that the chemical was being deployed into. We are happy to advise on this if required.
The major factor which contributes to the corrosion in hydro-static test water is the dissolved oxygen and dissolved solids do not have much impact on the corrosion rate except the chloride content. The presumptions like not using the corrosion inhibitor if the water is not with high mineral content could beM disastrous as in fact any corrosion process, even a very mild one, will be accompanied by the set up of galvanic cells and formation of corrosion products deposits. Such environment makes the conditions ideal for the corrosion process to continue at accelerated rate once the process fluid will be run through the line.
Pipeline corrosion inhibitor manufacturer and supplier. Hydro Testing Corrosion Inhibitor RXSOL 4000 provide complete protection against rust and scale.
